You can completely and quickly texture an imported model in 3D View in Texture display mode without using Blender materials.

#Blender fbx unity no colors update

The 3D view will now update and display the currently selected texture. In the UV editor, select a different image from the pick list.Select a polygon in the UV/image editor and press CTRL-L to expand the selection to all linked polygons.

Select a polygon in 3D view and use Select > Similar > Material, or.

To select a different image for part of your object shown in 3D view in Texture display mode, you will need to do the following: The image you have selected in the UV/image editor in edit mode is displayed in the UV/image editor as well as in 3D view when in Texture display mode. Again, for imported models you generally do not want to edit the UV layout. You can use G (move), R (rotate) and S (scale) to manipulate individual vertices, edges and polygons in 2D and 3D space simultaneously using a synced UV/image editor and 3D view side-by-side. If you are going to edit the UV layout and make minor changes, make sure ‘keep 3D and UV layout in sync’ is ticked. You can redo the UVWunwrapping and use Blender algorithms to unwrap the 3D object to 2D space, but this is not recommended for imported models as the image textures match with the current UV layout.

If you have a complex model and the texture image size is restricted i.e. If we look at the pictures again, you can see that the polygons of the selected object are unwrapped using two different images. Inspecting UV layout using UV/Image editor

RMB followed by SHIFT-CTRL-RMB (grow existing selection with shortest path between two points)Īdvanced selection methods are described in detail here:.

RMB followed by CTRL-RMB (shortest path between two points).

On a side note, in 3D view the following selection method is very useful for selecting connected edges, for example:

UV editor > Select a polygon followed by CTRL-L (select linked polygons).

There are a number of ways to select polygons in Blender: Basic selection methods Use the drop down list to select an image from the list. To load images use the image new/open/delete buttons at the bottom of the UV/Image editor. Vice versa, you can now select polygons in the UV/Image editor and they will show as selected on your object in 3D view. You can now select polygons on your object in 3D view and they will show as selected in the UV/image editor.

In the 3D view you will need to select an object and press TAB to enter edit (also known as sub-object) mode.

In the UV/image editor, select polygon mode and make sure ‘keep 3D and UV layout in sync’ is ticked.

In the lower left corner of the right hand side frame, select UV/image editor.

For each screen, press T to toggle the Tool shelf and press N to toggle the Properties (= numeric control) shelf.

You can grab and drag the divider line to move the split.

You can grab the same corner and drag it slightly to the right to remove the split.

Grab the top right corner of the 3D view and drag to the left to split the screen.In the pictures below you can see how the UV/image editor works. One of the first things to do when importing a model is inspect if the image textures map correctly to the mesh. For an imported model this has already been done – we simply need to inspect it. It is about unwrapping a 3D object onto a 2D surface. UV editing is where you gift wrap an object and then unwrap the paper to lay it flat. Odd.Īs said before, to avoid any unpleasant surprises, simply ensure all lights in your scene are deleted and Environment Lighting is active. For some reason, when you untick Render in Outliner the light will still affect your viewport. When in 3D view Texture display mode, lights will affect the viewport.

This is because imported materials only contain image texture and no specular highlight information (default material = all white specular map = specular highlights on your entire model). If you do have lights in your scene make sure to disable Specular when in 3D view Materials display mode. To avoid any unpleasant surprises, please ensure all lights in your scene are deleted and Environment Lighting is active. Hemi light or at the very least have basic Environment Lighting enabled. You can use Texture mode to simply slap a picture on a set of polygons.įor materials to be visible you will need to have lights in your scene i.e. In Blender you can select 3D view Materials display mode to see the effects of materials (diffuse, specularity, opacity, etc,). In this example we will not use the optional Nodes editor. Select this material as the main node in the Nodes editor. In this example the selected render engine is irrelevant.īlender comes with an optional Nodes material editor. Blender textures and materials + FBX export for Unityīlender comes with a built in Blender Render engine and a Cycles Render engine.
